OPTO-EDU A54.0720 Micromanipulator for Inverted Microscope

Name: OPTOEDU A540720 Micromanipulator for Inverted Microscope
Brand: CNOEC, OPTO-EDU
Price: 1 USD

Wholesale OPTO-EDU A54.0720 Micromanipulator for Inverted Microscope from china suppliers

Brand Name : CNOEC, OPTO-EDU

Model Number : A54.0720

Certification : CE, Rohs

Place of Origin : China

MOQ : 1 pc

Price : FOB $1~1000, Depend on Order Quantity

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

Delivery Time : 5~20 Days

Packaging Details : Carton Packing, For Export Transportation

Single axis moving distance : ≥20mm

Weights : 3.5 kg

Movement speed : 0~13000 um/s

Mechanical adjustment distance : 0~105 mm

Rotary axis offset angle : '-45°~110°

Speed control : Proportional and dynamic force feedback control

Contact Now

For Cell Microinjection Operations, Intracytoplasmic Sperm Injection (ICSI)
Equipped With Single-axis Motion And Three-axis Locking Functions
Step Motor, X/Y/Z Moving Range >20mm, Step Moving <20nm, Moving Speed 0~10mm/s,
Oil Pressure Microinjector 1000ul, Coarse Rotate 10ul, Fine Rotate 1ul, Air Pressure Microinjector 10ml, Coarse Rotate 600ul, Fine Rotate 60ul
Support YZ One Key Lock, , Z One Key Limit, One Key Release Control, One Key Zero, One Key Move to Memory Position

OPTO-EDU A54.0720 Micromanipulator for Inverted Microscope

The A54.0720 micromanipulation operating system has a Chinese/English bilingual interface. By controlling the rocking bar, cell microinjection operations can be carried out accurately and quickly, maximumly improving the success rate. A54.0720 is equipped with single-axis motion and three-axis locking functions, providing greater flexibility and convenience for Intracytoplasmic Sperm Injection (ICSI)

● Equipped with a Chinese/English bilingual interface.

● Good stability, no vibration during operation

● Adjustable microscope needle pitch and horizontal angle by knob

● The attachment functions can be selected and set.(Single-axis motion or locking, step injection)

● The Z-axis limit position can be set to prevent capillary breakage

▶ Suspension cell injection

Prokaryotic or cytoplasmic injection

Assisted Reproductive Technology ICSI operations

(intracytoplasmic single sperm injection)

▶ Suspension cell manipulation

Cell transplantation

Single-cell separation

▶ A54.0720 Micromanipulation Controller

Buttons, display, joystick and side dial are included. The movement direction and speed of the joystick are transmitted to the micromanipulation side through the control board. The movement speed and working range size can be predefined in the software. The working scope can be selected and changed individually on the control panel.

Micromanipulation controller	A joystick can be moved to control the movementdistance and direction of the X,Y, and Z axes
Speed control	Proportional and dynamic force feedback control
Work mode	Coarse/Fine /X-Fine
Size (LWH)	200290145 mm

Micromanipulation manipulator:

X. Y, Z three-axis motion mechanism, rotating connector and angle adjustment are included which is used to move and position the micromanipulation side in three-dimensional space.

Single axis moving distance	≥20mm
Weights	3.5 kg
Movement speed	0~13000 um/s
Mechanical adjustment distance	0~105 mm
Size(LWH)	140100240 mm
Rotary axis offset angle	-45°~110°

With good sealing performance, operations such as suspension positioning and cell removal of embryos can be carried out using air and oil.

Oil pressure microinjector and air pressure microinjector: for manual micro-volume high-precision injection, micro-volume liquid distribution injection and gas pressure control. 0l pressure microinjector is applied in complex scenarios with high resolution and high sensitivity (embryo biopsy and cell implantation, etc. Air pressure microinjector is a micro-transfer pneumatic micro-syringe, which is widely applied in scenarios like suspending cells, embryo maintenance, or transferring smaller volumes of liquid.

Oil pressure microinjector
Function	Aspiration and dispensing of microcells Manual microinjection Cell removal
Medium	Paraffin oil
Volume change per revolution	1uL/10uL
Maximum volume	1000uL
Injection tube	1.3 meters long, inner diameter 1.0 mm, outer diameter 2.0 mm

Air pressure microinjector
Function	Microcell suspension maintenance Aspiration and dispensing of microcell Small volumes of liquids trace dispensing
Pressure generation	Air
Volume change per revolution	60uL/600uL
Maximum volume	10mL
Injection tube	1.3 meters long, inner diameter 1.0 mm, outer diameter 2.0 mm
