Medical Stereo Optical Microscope Fluorescent Light Microscopes CE A23.0901-ST

  • 1
  • 2
  • 3

Place of Origin : China

Brand Name : CNOEC, OPTO-EDU

Certification : CE|Rohs

Model Number : A23.0901-ST

MOQ : 1 pc

Price : FOB $1~1000, Depend on Order Quantity

Packaging Details : Carton Packing, For Export Transportation

Delivery Time : 5~20 Days

Payment Terms : T/T, West Union, Paypal

Supply Ability : 5000 pcs/ Month

Applications : Jewelry|Medical

Drawtube : Binocular|Trinocular

product name : stereo zoom microscope

Theory : Stereo Microscope

magnification : 7x - 45x

Contact Now

Description:

--0.7~4.5x Zoom Lens, with WF10x/20mm Eyepiece,
--Total Optical Magnification 7~45x
--Up 12V 15W Halogen & Bottom 230V 7W Fluorescent Light
--110~240V Wide Range Voltage

Specifications:

A23.0901-ST Zoom Stereo Microscope Specification

2B

2T

3B

3T

Head

Binocular Head, 45° inclined, 360°Rotatable, ±5 Diopter Adjustable,

Interpupillary Adjustment 54-75mm

o

o

Trinocular Head, 45° inclined, 360°Rotatable, ±5 Diopter Adjustable,

Interpupillary Adjustment 54-75mm

o

o

Eyepiece

WF10x/20mm, High Eyepoint

Zoom Lens

0.7~4.5x

Zoom Ratio

1:6.5

Magnification

7x-45x, Up to 3.5x-180x With Optional Eyepieces and Auxiliary Objectives

Working Distance

100mm, With Auxiliary Objectives 30~165mm

Field of View

1~95.2mm

Stand

Pole Stand ST2/ST3, Height 248mm, Base 200*255*60mm

Light Source

Up 12V 15W Halogen & Bottom 12V 15W Halgen Light

o

Up 12V 15W Halogen & Bottom 230V 7W Fluorescent Light

o

Power

110~240V Wide Range Voltage

A23.0901-ST Zoom Stereo Microscope Optical Data Sheet

Objective

Standard 1.0x

Auxiliary 0.5X

Auxiliary 1.5X

Auxiliary 2X

W,D.

100mm

165mm

45mm

30mm

Eyepiece

Mag

View field

Mag

View field

Mag

View field

Mag

View field

10X/20mm

7.0X

28.6mm

3.5X

57.1mm

10.5X

19mm

14X

14.3mm

45.0X

4.4mm

22.5X

8.9mm

67.5X

3mm

90X

2.2mm

15X/15mm

10.5X

21.1mm

5.25X

42.8mm

15.75X

14.3mm

21X

10.7mm

67.5X

3.3mm

33.75X

6.7mm

101.25X

2.2mm

135X

1.7mm

20X/10mm

14.0X

14.3mm

7.0X

28.6mm

21.0X

9.5mm

28X

7.1mm

90.0X

2.2mm

45.0X

4.4mm

135.0X

1.5mm

180X

1.1mm

A23.0901-ST Zoom Stereo Microscope Optional Accessories

Cata. No.

Head

Binocular Head + WF10x/20mm

A23.0901-BH

Trinocular Head + WF10x/20mm

A23.0901-TH

Eyepiece

WF10x/20mm, High-eyepoint, Outside Dia. 30mm

A51.0922-10

WF15x/15mm, High-eyepoint, Outside Dia. 30mm

A51.0922-15

WF20x/10mm, High-eyepoint, Outside Dia. 30mm

A51.0922-20

WF10x/20mm,with Reticle

A51.0932-10

WF15x/15mm,with Reticle

A51.0932-15

WF20x/10mm,with Reticle

A51.0932-20

Auxiliary Lens

0.5X,W.D. 165mm

A52.0927-05

0.75X,W.D. 105mm

A52.0927-75

1.5X,W.D. 45mm

A52.0927-15

2.0X,W.D. 30mm

A52.0927-20

CCD Adapter

0.50x, For 1/2" CCD

A55.0932-05

0.35x, For 1/3" CCD

A55.0932-35
